TITAN side loader is undeniably the ultimate reference in the side loader industry.
TITAN container side loader easily adapts to your operations, making it safe and secure, even in rough operations. It can lift the heaviest containers, even badly positioned or with unevenly reparted load inside. The double extension stabilizers give it impressive stability, allowing you to work on soft or uneven ground.
The multiple applications possible with the side lifter make it an indispensable tool for your organization, whether it is for transfers, grounding, lifting or double stacking.
New and Used Side Loader Trailers for Sale In Dominica
1)Double stacking of containers
Lack of space is a recurrent feature of today’s logistics world. Double stacking of containers can be a very useful and economic solution. Titan side lifters can double stack two high cube containers on the ground without chain shorteners. It avoids to invest in a specific equipment. Do not hesitate to contact our teams so we can discuss together the perfect product to match your needs.
2)Transfer from/to other trailers
When several containers must be delivered in the same yard, Container side lifter can pick up the containers on the companion trailers to ground them. Waiting time for trucks and trailers is drastically reduced, thus improving the efficiency and profitability of each trip.
40Ft Side Lifters Trailer for Sale Price
3)Grounding and lifting of containers
Grounding and lifting represent 90% of a sidelifter’s tasks. Once on the ground, the 45t sidelifter goes to another job, while the container can be stuffed or unstuffed more easily, without the need of specific infrastructure such as platforms or loading ramps. Forklifts can therefore enter the container. Side container loader range of equipments allows to handle containers even on rough ground. Do not hesitate to contact our teams so we can discuss together the perfect product to match your needs.
TITAN Sidelifter adopt remote control which is made to order for ambient environment ,performance need, operation process and standard, What we used is wireless remote control, its receivesr need to fixed installating, The protection grade of the receiver is very high, it can be installed in the open air.
But it may prolong the service life of the receiver if installe it in the electric control cabinet.
Side Loader Trailer Manufacturer
1) The first is knob switch, is start and alarm switch: System get through power just or enter into sleeping state, only shift the switch can start remote control ( alarm sending out signal at this time). When need to give alarm, shift the switch to the position marked , when release it, the switch will back to the original position, alarm is stopped.
2) The third is knob on-off, used for compulsory operation after anti-turnover control. Shift switch to the once, shield anti-turnover of 5s (system can’t carry on anti-turnover control, can carry on compulsorily operation at this time ), it is only available shift it again after 30s interval.
3) The fourth is the self-lock switch, which is used for controlling speed: high speed is denoted by the “rabbit” pattern; high speed is denoted by the “tortoise” pattern.
4)The fifth switch is an emergency stop, press emergency stop and power is switched off, all movement stopped.
5) The sixth is the self-lock switch, used for selecting operation mode: 0-no operation, L-LEG-leg operation mode, B-BOOM-boom operation mode.
Details of 45T Side Loading Trailer
6) The seventh is self-lock switch, used for selecting operation mode: when nonsynchronization (shift switch to the “NONSYNC.”): left side handle to control the motion of front lifting, and right side handles to control the motion of rear lifting; when synchronization (shift switch to the “ SYNC.”) left side handle can control the motion of front and rear lifting simultaneously, the right side handle has no effect.
7) The eighth is self-reset switch, main used for selecting frequency.
8) The handles on the top both sides are universal proportion handle, used for lifting/dropping upper boom, swinging down boom, lifting/dropping support leg, retracting/extending support leg.
9) Remote control or other place is equipped with a buzzer, which is used for warning person of the low power supply , of course, at the same time, buzzer can sounds to warn person of the condition.
10) Other button and knob switch are spare.
