The Container lift trailer is a container-specific loading and unloading, which is used in container terminals and transfer yards. The role of side loader container trailer is to realize container handling, such as loading and unloading of container flatbed trailer.
TITAN 40ft container self loading trailer is used for loading and unloading 20ft and 40ft containers.
TITAN Container side loader have made work flexible, Save time and improve productivity for satisfied customers around the world.We adopt World famous brand parts of the side lifter cranes.
Trailer side loader
1. Timesaving and improve efficiency: TITAN Sidelifter can be productive all day, enabling loading, unloading and transporting containers by itself easily.
2. Flexible solutions: With the TITAN 40ft Container Self Loading Trailer, you get closer and can lift between trailers safely and with high precision.
3. Famous WABCO braking valve, JOST landing gear for the main chassis container skeleton trailer
4. Famous NBB Germany Remote Control, easy to operate
5. TITAN 40ft Container Self Loading Trailer adpots wireless remote control technology, loading container just takes 10 mins.
Container loading
• Detailed operating instructions also ,we have the Video Explanation
• Overseas engineer to provide technical service
• You can reach us at any time and get a rapid response
• Competent technical service ,
• Rapid and safe deliveries of spare parts
Side loader truck
Max.lifting capacity ：37 ton
Funtion：Load 20ft and 40ft container trailer
Trailer Chassis：14100mm * 2500mm *4100mm
Axles：3 axles
Tire：12 units
King pin：90#
Langing gear：JOST
Power source：Power take off/Diesel APU
Opeartion ：Wireless remote control and Manual opeartion
